| AVAILABLE OPTIONS: |
chip contact initializing on each hopper. LinkWare
application for in-line operation with other Pro-Series equipment.
SDK Software Developer Kit. Floor stand unit for Pro-Series. |
| CARD HANDLING - Card dimensions: |
card size ISO standard CR-80 (86x54 mm) |
| CARD HANDLING - Card thickness: |
0,40mm till 0,80mm |
| CARD HANDLING - Input hopper capacity: |
n. 6 input hoppers, 200 cards each (0,76 mm) |
| CARD HANDLING - Negative hopper: |
40 cards |
| CARD HANDLING - Output hopper capacity: |
200 cards |
| COMMUNICATION INTERFACE: |
Serial RS232 port and parallel port |
| DIMENSIONS AND WEIGHTS - Dimensions of floor base: |
WxDxH= 700x430x880 mm |
| DIMENSIONS AND WEIGHTS - Dimensions with floor base: |
WxDxH= 860x500x1220 mm |
| DIMENSIONS AND WEIGHTS - Weight with floor base: |
kg. 99,6 |
| DIMENSIONS AND WEIGHTS - Weight: |
kg. 54,6 |
| DIMENSIONS AND WEIGHTS: - Physical dimensions: |
WxDxH= 860x480x350 mm |
| ELECTRICAL REQUIREMENTS: |
117V / 60Hz – 230V / 50Hz |
| MEMORY AND DATA : - Miscellanea: |
Lithium back-up battery. Security operation with key
lock |
| MEMORY AND DATA : - Software/Firmware : |
Windows based application software. Self diagnostic;
automatic reception of faulty card; clearable and not-clearable
counters. System status and diagnostic messages reported on
PC. |
| OPERATING TEMPERATURE: |
10°C + 35°C |
| POWER CONSUMPTION: |
AS MULTIFEEDER: 150 Watt; including chip option 250
Watt. |
| RELATIVE HUMIDITY: |
20% - 85% non condensing |
| |
|
